Parker MAC air oil cooler with AC motor for marine applications

in ,

High-performance cooling solutions for the marine industry

Parker MAC Air Oil Cooler with AC Motor for Marine Applications

Overview

The Parker MAC series air oil cooler with AC motor is engineered to provide high-performance cooling solutions for marine and offshore applications. With a cooling capacity of up to 300 kW, it ensures the efficient and reliable operation of hydraulic systems even in the harshest marine environments. Designed to withstand corrosive conditions and meet C5M-M standards (ISO 12944), the MAC series offers an optimal balance between performance, durability, and sustainability.

At A&C Engineering, we proudly offer the Parker MAC Series Air Oil Cooler as a premier cooling solution tailored to the specific needs of the marine industry.

Download the MAC Series Air Oil Cooler with AC motor for Marine Applications catalog

Key features and benefits

1. Robust and corrosion-resistant design

The MAC series is specially built to endure the extreme conditions of offshore marine applications. Key corrosion-resistant features include:

  • C5M-M compliance for maximum protection in marine environments
  • 720-hour salt spray resistance, tested per ISO 9227 standards
  • Tropicalized paint protection inside the motor and connection box
  • A4 stainless steel fasteners and cast iron motor housing for extended durability

2. Superior cooling performance

Designed for efficiency and high cooling capacity up to 300 kW, the Parker MAC Air Oil Cooler optimizes the performance of hydraulic systems by:

  • Reducing oil temperature fluctuations
  • Preventing hydraulic system overheating
  • Enhancing system efficiency and longevity

3. Optimized for marine and offshore applications

The MAC Series is the ideal cooling solution for various marine and offshore applications, including:

  • Deck machinery: Winches, shark jaws, guide pins
  • Ship equipment: Steering gear, hydraulic power units
  • Cargo handling: Ship cranes, hatch covers
  • Wind power: Turbine generators and electrical cabinets

4. Easy and secure installation

Installation of the MAC Series is straightforward and safe, thanks to:

  • Safe and secure lifting points for easy transportation
  • Rounded feet to prevent damage and enhance corrosion resistance
  • Pre-drilled cable clamp holes to simplify motor wiring, eliminating the need for additional drilling or welding

5. Simplified maintenance for longevity

With minimal mechanical interference and a reduced number of components, the MAC Series ensures easy maintenance and spare parts management. Other maintenance-friendly features include:

  • A4 stainless steel fasteners, allowing for disassembly without compromising corrosion protection
  • Drainage holes in the fan housing to prevent water accumulation
  • One-piece fan guard and motor bracket for improved air resistance and durability

Technical specifications

1. Performance and compliance

  • Cooling capacity: Up to 300 kW
  • Maximum operating pressure: 21 bar
  • REACH & RoHS compliant
  • LVD and EMC compliant
  • Safety machinery standards: ISO 12100, ISO 4413, ISO 13857

2. Construction and materials

  • Motor housing: Cast iron with stainless steel shaft
  • Fasteners: A4 stainless steel with additional corrosion prevention treatment
  • Fan: Anodized aluminum boss for increased durability
  • Protective coating: 720-hour neutral salt spray tested (ISO 9227 compliance)
  • Paint protection: Tropicalized coating inside motor and connection box

3. Electrical motor specifications

  • Voltage and frequency options:
    • 230/400V 50Hz
    • 265/460V 60Hz
    • 500V 60Hz
    • 400/690V 50Hz
    • 525V 50Hz
    • 575V 60Hz
    • 690V 60Hz
  • Motor protection rating: IP56 for superior water and dust resistance
  • Available with a heater for extreme conditions

Why choose Parker MAC air oil coolers for marine applications?

Unmatched reliability in harsh conditions

The Parker MAC Series is built to last, with a rugged construction that ensures longevity in highly corrosive environments. Whether operating in nearshore or offshore settings, this cooler delivers consistent performance with minimal downtime.

Energy-efficient and environmentally friendly

  • Low noise levels, ensuring a user-friendly and less disruptive operation
  • Compliant with global environmental regulations (REACH & RoHS)
  • High energy efficiency, leading to reduced operating costs

Versatile and customizable

With a wide range of cooler sizes, fan configurations, and electrical options, the MAC Series is adaptable to diverse marine applications. The variety of available accessories, such as stone guards, dust guards, and bypass valves, further enhance customization.

Proven excellence by Parker Hannifin

With decades of experience in cooling solutions, Parker Hannifin ensures that each MAC Series Air Oil Cooler meets the highest industry standards. This makes it a trusted choice for marine professionals worldwide.

Order your Parker MAC air oil cooler today

At A&C Engineering, we specialize in high-performance cooling solutions for marine applications. The Parker MAC Air Oil Cooler is a game-changer for marine and offshore industries, providing efficient, corrosion-resistant, and long-lasting cooling solutions.

Contact us now

For more information, product specifications, or to request a quote, reach out to our team today!
